DS-PSA Oxygen generator
PREMIUM PLUS
NOVAIR, a French pioneer in on-site medical oxygen, continues to innovate with solutions that are both robust and intelligent. Today, we present PREMIUM PLUS, a very high-purity oxygen generator based on patented DS-PSA technology. Reliable, scalable, and easy to use, it stands out as the benchmark for demanding healthcare facilities.
- Adjustable purity from 96% to 99.5%, produced on site and on demand.
- Exceptional concentration stability (±0.2%), even at high flow.
- Intuitive touchscreen interface, local or remote operation, and simplified maintenance.
Why choose PREMIUM PLUS?
Customizable purity
PREMIUM PLUS produces medical oxygen ranging from 96% to 99.5%, with exceptional stability of ±0.2%. Users can adjust the purity according to their needs, while maintaining quality compliant with the most strict standards and suited to hospital applications.
Continuous stability
Thanks to dual-stage DS-PSA technology and the OCS module, concentration remains constant even during periods of high demand. The system automatically adjusts parameters to ensure reliable flow and controlled purity at all times.
Advanced monitoring
The 10” Visio HD touchscreen interface, featuring a multilingual user interface, provides comprehensive production monitoring, continuous 24/7 data logging, and secure remote access. Data, alarms, and performance curves are archived, ensuring precise control and optimized maintenance.
Advantages of PREMIUM PLUS
Adjustable-purity oxygen production
PREMIUM PLUS produces medical oxygen from ambient air, with adjustable purity between 96% and 99.5%, thanks to dual-stage DS-PSA technology. Ideal for operating theatres, intensive care units, and critical situations. Concentration stability (±0.2%) is ensured even during periods of high demand.
Continuous performance and integrated monitoring
The Visio HD 10” control panel provides a complete view of production parameters.
- Reduced logistics costs: no more cylinder deliveries
- Permanent autonomy, 24/7 operation
- Reliable oxygen supply, compliant with the most stringent medical standards.
- The outlet pressure is available as standard at 6 or 10 bar.
PREMIUM PLUS oxygen generator in detail
Key features
The generator adjusts its production cycles in real time according to variations in oxygen consumption within the healthcare facility, while optimizing energy efficiency.
- DS-PSA technology with high-performance molecular sieves
- Side control panel featuring a calibration system
- 10″ touchscreen, Visio HD panel with multilingual interface
- Traceability system with history of alarms, production data, and critical parameters
Technical data
CE medical device – Class IIb, compliant with EN ISO 7396-1, designed to analyze multiple pollutants and parameters in real time with high accuracy.
- Adjustable oxygen purity up to 99.5%, with stability of ±0.2%
- Maximum flow rate at 99.5%: from 2.7 to 42 Nm³/h depending on the model; contact us for higher capacities
- Outlet pressure: 6 or 10 bar (no booster required)
- Required compressed air quality: ISO Class 1.4.1
- Power supply: single-phase & three-phase – 50/60 Hz
DS-PSA technology
Pressure Swing Adsorption (PSA) is a static gas separation process that extracts gases from air using a molecular sieve capable of adsorbing nitrogen under pressure. The result of several years of R&D efforts and investment, DS-PSA technology is based on a two-stage PSA process: with its two molecular separators, PREMIUM PLUS removes nitrogen, argon, and then all remaining traces of pollutants. This process makes it possible to achieve an oxygen purity of up to 99.5%.
Are you preparing a tender or a technical specification file?
Our team provides a complete set of special technical specifications (CCTP), including:
- Functional description of the PREMIUM PLUS oxygen generator
- Technical and environmental requirements
- Integration into existing medical gas networks
- Compliance with European monograph Oxygen 98%
Contact us to receive the CCTP adapted to your project:
